SSL152x
SMPS ICs for mains LED drivers
Rev. 3 — 17 September 2010
Product data sheet
1. General description
The SSL152x family is a Switched Mode Power Supply (SMPS) controller IC that operate
directly from the rectified universal AC mains. It is implemented in the high-voltage Easy
High Voltage Silicon-On-Insulator (EZ-HV SOI) process, combined with a low-voltage
Bipolar Complementary Metal Oxide Semiconductor (BiCMOS) process. The device
includes a high-voltage power switch and a start-up circuit that operates directly from the
rectified mains voltage.
A dedicated circuit for valley switching is built in, which makes a very efficient slim-line
electronic concept for solid state lighting applications possible.
The SSL152x family can operate in applications with a power range of up to 15 W.
Applications in the range between 15 W and 25 W are more suited to the SSL1623PH.
LED powers above 25 W are more suited to the SSL1750.
In the most basic applications, the SSL152x family act as a voltage source. Here, no
additional secondary electronics are required. A combined voltage and current source can
be realized with minimum costs for external components. Implementation of the SSL152x
family renders an efficient and low cost power supply system for mains LED drivers.
2. Features and benefits
Designed for mains LED drivers up to 15 W
Integrated power switch:
SSL1522T: 12 Ω ; 650 V
SSL1523P: 6.5 Ω ; 650 V
Operates from universal AC mains supplies (80 V to 276 V)
Adjustable frequency for flexible design
RC oscillator for load insensitive regulation loop constant
Valley switching for minimum switch-on loss
Low standby power (< 100 mW) with frequency reduction at low power outputs
Adjustable overcurrent protection
Undervoltage protection
Temperature protection
Short-circuit winding protection
Simple application with both primary and secondary (opto) feedback
Available in DIP8 and SO14 packages
